WG26 input RFID keypad proximity Punch card Access Control

FOB Reference Price:Get Latest Price
US $11.99-38.9 / Piece | 1 Piece/Pieces Punch card Access Control factory price (Min. Order)
Supply Ability:
50000 Unit/Units per Month
Port:
Shenzhen
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
HSY
Model Number:
HSY-S208
Product name:
Punch card Access Control
Model:
HSY-S208
Wiegand Signal:
Wiegand26 input, can connect external reader
Card capacity:
1,000
Frequency:
125 kHz
Power:
DC12V 3Amp
Certificate:
CE
Packaging & Delivery
Packaging Details
Punch card Access Control package: 1pcs per box, 50pcs per carton.
Delivery Time
2~5 days

WG26 input RFID keypad proximity Punch card Access Control





Product Description



Punch card Access Control Description:



The unit is single door multifunction standalone access controller or a Wiegand output
keypad or card reader. It is suitable for mounting indoor. It is housed in a strong, sturdy
and vandal proof Zinc Alloy electroplated case which is available in either a bright silver or
matt silver finish. This unit supports up to 2000 users in either a Card, 4 digit PIN, or a
Card + PIN option. The inbuilt card reader supports 125KHZ EM cards. The unit has many
extra features including lock output current short circuit protection, Wiegand output , a
backlit keypad and anti tamper ect. These features make the unit an ideal choice for door
access not only for small shops and domestic households but also for commercial and
industrial applications such as factories, warehouses, laboratories, banks and prisons.





Punch card Access Control Features:



Strong Zinc Alloy Electroplated anti-vandal case

Full programming from the keypad
2000 uses, supports Card, PIN, Card + PIN
Can be used as a standalone keypad
Backlight keys
Wiegand 26 input for connection to external reader
Wiegand 26 output for connection to a controller
Adjustable Door Output time, Alarm time, Door Open time
Very low power consumption (30mA)
Fast operating speed, <20ms with 2000 users
Lock output current short circuit protection
Easy to install and program
Built in light dependent resistor (LDR) for anti tamper
Built in buzzer



Punch card Access Control Specifications:



Punch card Access Control more views:







One unit package included:







Operation Installation:



1.  Remove the back cover from the keypad using the normal screw driver

2.  Drill 2 holes on the wall for the Self tapping screws and 1 hole for the cable

3.  Put the supplied rubber bungs to into the two holes

4.  Fix the back cover firmly on the wall with 2 Self tapping screws

5.  Thread the cable through the cable hole

6.  Attach the keypad to the back cover.







To Reset to Factory Default



a. Disconnect power from the unit
b. Press and hold # key whilst powering the unit back up
c. On hearing two “Di” release # key, system is now back factory settings



Attention:



Please note only installer data is restored, user data will not be affected.



Wiring Discription:







Related Products:







Company information







Packaging & Shipping
1pcs per box, 50pcs per carton.

1. FedEx/DHL/UPS/TNT for samples, Door-to-Door service;
2. By Air or by Sea for bulk goods, for FCL; Airport/ Port receiving;
3. Support Customers specifying freight forwarders or selected shipping methods!





FAQ
1. How we can trust you?
    We are Alibaba Trade Assurance Supplier and 6 years Ali Gold Supplier.
    HSY has been verified by Bureau Veritas Application.
2.  Why choose us?
        With us make Win-Win Business Situation!!!
        24 *7 hours after sales service
        We can accept "PayPal" the most easy payment way
        Quality Assurance Contract
        Full refund in case of bad quality
        Online supports if any technique issue.
        Small Order or Big Order all accept ( OEM/ODM)
3.  What's your MOQ?
       Big Order or Sample Order all accept by our company.
       We understanding new customers may take sample testing to know our quality and service.
4.  What is the warranty?
      2 years warranty from the date of delivery,A lifetime technical support.
      and we will return full money to customer if we did not shipping right items as contract.
5.  What’s your delivery time?
       Around 2~10 working days according to exact order quantity and stock situation.
6.  What’s your Payment?
       PayPal or T/T(Bank transfer) or Western Union also Ali trade Assurance.
7.  Your products can be customized?
        Yes,sure. pls talking to sales about your exact requirements.
        HSY offer the OEM or ODM service.
